Heavy-Duty Vertical CNC Turning Centers GV-1

OPTIMIZED EQUIPMENT

ATC System

High reliable BT50 12 / 16 / 24 T umbrella type ATC system which providing 50 kg maximum tool weight and 360 kg maximum magazine loading capability.

Fully enclosed ATC door only opened when tool change. ATC won't be damaged by cutting chips that can make sure tool changing reliability.


ATC System
ATC System 2
Coolant Through Spindle

Coolant Through Spindle

optional
Automatic Tool Length Measurement

Automatic Tool Length Measurement

optional
Workpiece Inspection Probe

Workpiece Inspection Probe

optional
High Pressure Coolant System
optional

Max. Pressure ： 70 ~ 100 bar ( 1,000 ~ 1,500 PSI )
Max. Flow Rate ： 30 ~ 53 LPM ( 8 ~ 14 GPM )
Coolant Type ： Water or Oil

  • Pressure output monitoring system
    		•
  • Patented diaphragm pump ( made in USA. )
    		•
  • Filter replacement checking
    		•
  • Touch screen of human machine interface
    		•
  • Super large capacity coolant tank ( optional sub coolant tank )
    		•
    High Pressure Coolant System
    Intelligent Automatic Pressure Control
  • Pressure controlled by programmable valve control, no need to be adjusted by manual, more accurate pressure output.
    		•
  • It is controlled by closed loop of inverted motor, it can be adjusted to proper flow automatically by pressure to save power and
         decrease heat raising of coolant.*1
    		•
  • Use Ethernet to connect*2 with machine, easy wiring and setting, save cost of purchasing hardware.
    		•
    *1 Traditional manual adjusting way is constant frequency full flow output.
    *2 Only FANUC / SIEMENS controller
